IP65 20HP Rotary Industrial Screw Air Compressor Direct Driven

Brand Name : China

Model Number : PMVFQ15

Certification : ISO9001,CE

Place of Origin : China

MOQ : 1 set

Price : $7000-20000per set

Supply Ability : 100set per month

Delivery Time : 3-15 days

Packaging Details : 1.plywood cases suitable for sea transportation 2.as customer's requirement

Working pressure : 0.6-0.9MPa

Power : 20HP rotary screw air compressor

Transmission way : Direct driven

Type : VSD Screw air compressor

Stage : Two stage compression

Lubrication style : Oil injected

Cooling method : Air cooling

Voltage : 380V 50HZ 3phase (customize)

Contact Now

Silk High end series-PMVFQ15 Variable Speed Screw Air Compressor

A high-efficiency PM variable screw air compressor has advantages in the following three areas:
1> The first is to have a highly efficient screw compression unit;

2> Secondly to have a highly-efficient PM synchronous motor;

3> Thirdly to have first-class PM variable frequency control technology.
Silk PM variable frequency air compressor possesses significant technical advances in the three areas.

PMVFQ15 Technical Parameters
Screw set 5:6 toothed rotor
Compression method Continuous/single stage
Exhaust interface P2=0.6-1.0MPa
Cooling method Air cooled
Output temperature 10℃~15℃higher than ambient temperature
Amount of lubricant About 15L
Motor speed N=4135-5224r/min
Rated power 15kW/20HP(IP65)
Exhaust volume V=2.37-2.88m3/min
Working weight 380kg
Air temperature upper limit 45℃
Air temperature lower limit 0℃
Fuel consumption <2PPM
Noises 68dB(A)
Dimensions

1200x830x1240mm

Model
Max. Pressure
(bar)
Max. Capacity
(m3/min)
MotorPower
(kw/hp)
Air outlet
Dimension
(cm)
Weight
(kg)
PMVFQ15
9
2.88
15/20
1"
120*83*124
380
PMVFQ22
9
4.22
22/30
1"
120*83*129
480
PMVFQ37
9
7.42
37
1.5"
140*100*154
710
PMVFQ45
9
9.27
45
1.5"
150*116*170
990
PMVFQ55
9
11.95
55
1.5"
150*116*170
990
PMVF22-II
9
4.6
22
1"
165*90*111
550
PMVF37-II
9
7.65
37
1.5"
182*100*114
740
PMVF55-II
9
12.5
55
1.5"
210*120*133
1100
PMVF75-II
9
16.5
75
2"
216*122*158
1450


IP65 20HP Rotary Industrial Screw Air Compressor Direct DrivenIP65 20HP Rotary Industrial Screw Air Compressor Direct DrivenIP65 20HP Rotary Industrial Screw Air Compressor Direct DrivenIP65 20HP Rotary Industrial Screw Air Compressor Direct Driven​

Customers Benefit

1. A economical and practical machine cansatisfy demand of user from the small power consumption, low price of screw compressor.
2. New generation of low consumption and high efficiency motor , larger starting torque, with SKY Bearing, low noise.
3. Dual nested Optimizer separator elements. reduce fluid carryover to a maximun of 1 ppm.
4. Computer-compatible microprocessor controller has simple graphic illustration of monitored functions
